130. Surrounded Regions - Explanation

Description

You are given a 2-D matrix board containing 'X' and 'O' characters.

If a continous, four-directionally connected group of 'O's is surrounded by 'X's, it is considered to be surrounded.

Change all surrounded regions of 'O's to 'X's and do so in-place by modifying the input board.

Example 1:

Input: board = [
  ["X","X","X","X"],
  ["X","O","O","X"],
  ["X","O","O","X"],
  ["X","X","X","O"]
]

Output: [
  ["X","X","X","X"],
  ["X","X","X","X"],
  ["X","X","X","X"],
  ["X","X","X","O"]
]

Explanation: Note that regions that are on the border are not considered surrounded regions.

Constraints:

1 <= board.length, board[i].length <= 200
board[i][j] is 'X' or 'O'.

Recommended Time & Space Complexity

You should aim for a solution with O(m * n) time and O(m * n) space, where m is the number of rows and n is the number of columns in the matrix.

Hint 1

We observe that we need to capture the regions that are not connected to the O's on the border of the matrix. This means there should be no path connecting the O's on the border to any O's in the region. Can you think of a way to check the region connected to these border O's?

Hint 2

We can use the Depth First Search (DFS) algorithm. Instead of checking the region connected to the border O's, we can reverse the approach and mark the regions that are reachable from the border O's. How would you implement this?

Hint 3

We run the DFS from every 'O' on the border of the matrix, visiting the neighboring cells that are equal to 'O' recursively and marking them as '#' to avoid revisiting. After completing all the DFS calls, we traverse the matrix again and capture the cells where matrix[i][j] == 'O', and unmark the cells back to 'O' where matrix[i][j] == '#'.

Company Tags

Please upgrade to NeetCode Pro to view company tags.

1. Depth First Search

class Solution:
    def solve(self, board: List[List[str]]) -> None:
        ROWS, COLS = len(board), len(board[0])

        def capture(r, c):
            if (r < 0 or c < 0 or r == ROWS or
                c == COLS or board[r][c] != "O"
            ):
                return
            board[r][c] = "T"
            capture(r + 1, c)
            capture(r - 1, c)
            capture(r, c + 1)
            capture(r, c - 1)

        for r in range(ROWS):
            if board[r][0] == "O":
                capture(r, 0)
            if board[r][COLS - 1] == "O":
                capture(r, COLS - 1)

        for c in range(COLS):
            if board[0][c] == "O":
                capture(0, c)
            if board[ROWS - 1][c] == "O":
                capture(ROWS - 1, c)

        for r in range(ROWS):
            for c in range(COLS):
                if board[r][c] == "O":
                    board[r][c] = "X"
                elif board[r][c] == "T":
                    board[r][c] = "O"

Time & Space Complexity

Time complexity: $O(m * n)$
Space complexity: $O(m * n)$

Where $m$ is the number of rows and $n$ is the number of columns of the $board$ .

2. Breadth First Search

class Solution:
    def solve(self, board: List[List[str]]) -> None:
        ROWS, COLS = len(board), len(board[0])
        directions = [(1, 0), (-1, 0), (0, 1), (0, -1)]

        def capture():
            q = deque()
            for r in range(ROWS):
                for c in range(COLS):
                    if (r == 0 or r == ROWS - 1 or
                        c == 0 or c == COLS - 1 and
                        board[r][c] == "O"
                    ):
                        q.append((r, c))
            while q:
                r, c = q.popleft()
                if board[r][c] == "O":
                    board[r][c] = "T"
                    for dr, dc in directions:
                        nr, nc = r + dr, c + dc
                        if 0 <= nr < ROWS and 0 <= nc < COLS:
                            q.append((nr, nc))

        capture()
        for r in range(ROWS):
            for c in range(COLS):
                if board[r][c] == "O":
                    board[r][c] = "X"
                elif board[r][c] == "T":
                    board[r][c] = "O"

Time & Space Complexity

Time complexity: $O(m * n)$
Space complexity: $O(m * n)$

Where $m$ is the number of rows and $n$ is the number of columns of the $board$ .

3. Disjoint Set Union

class DSU:
    def __init__(self, n):
        self.Parent = list(range(n + 1))
        self.Size = [1] * (n + 1)

    def find(self, node):
        if self.Parent[node] != node:
            self.Parent[node] = self.find(self.Parent[node])
        return self.Parent[node]

    def union(self, u, v):
        pu = self.find(u)
        pv = self.find(v)
        if pu == pv:
            return False
        if self.Size[pu] >= self.Size[pv]:
            self.Size[pu] += self.Size[pv]
            self.Parent[pv] = pu
        else:
            self.Size[pv] += self.Size[pu]
            self.Parent[pu] = pv
        return True

    def connected(self, u, v):
        return self.find(u) == self.find(v)

class Solution:
    def solve(self, board: List[List[str]]) -> None:
        ROWS, COLS = len(board), len(board[0])
        directions = [(1, 0), (-1, 0), (0, 1), (0, -1)]
        dsu = DSU(ROWS * COLS + 1)

        for r in range(ROWS):
            for c in range(COLS):
                if board[r][c] != "O":
                    continue
                if (r == 0 or c == 0 or
                    r == (ROWS - 1) or c == (COLS - 1)
                ):
                    dsu.union(ROWS * COLS, r * COLS + c)
                else:
                    for dx, dy in directions:
                        nr, nc = r + dx, c + dy
                        if board[nr][nc] == "O":
                            dsu.union(r * COLS + c, nr * COLS + nc)

        for r in range(ROWS):
            for c in range(COLS):
                if not dsu.connected(ROWS * COLS, r * COLS + c):
                    board[r][c] = "X"

Time & Space Complexity

Time complexity: $O(m * n)$
Space complexity: $O(m * n)$

Where $m$ is the number of rows and $n$ is the number of columns of the $board$ .
